Outdoor Wireless Doorbell

WSDCAM Tuya Wifi Cat Eye Doorbell Camera Outdoor Wireless Visual Doorbell Waterproof Smart home Security Alarm

Product parameters

Processor: Hi3518E

Memory: RAM 512M

Operating system: liveOS

Imaging chip: 720p

Screen specifications: 4.3 inches, IPS, 480*272

Battery capacity: ≥3000mAh

Surveillance intercom: Support

Mobile detection: support

External storage: Micro SD card (maximum support 128GB)

Night Vision wavelength: 940nm (invisible light)

Charger: 5V/2A

Suitable for door holes: diameter 14-35 mm

Applicable door thickness range: 35-100 mm

Wireless WiFi: IEEE802.11b/G/N 2.4GHz

2.4G Wifi Connect Directly (Not Support 5G WIFI)

The doorbell can connect 8 mobile phones at the same time.

4.3inch tow-way intercom Tuya Peephole Doolbell

130 ° Ultra Wide Angle:

Equipped with a 130 ° wide -angle lens, you can see the wider space outside the door，With 120 ° wide -angle lens, you can see a wider space outside the door.

The mobile app push the message at any time, which can better protect you

PIR Mobbile Detection:

photo/video Recording      APP Message Push          View AccessReal-time Two Way Audio:

Built-in mic & speaker, real-time talking with the visitors no matter wherever you were. In addition to, this doorbell has anti-noise technology, it will make the conversation clearer and smoother.

(Note: Display screen can’t support two-way audio, only use APP can talk with visitors.)

Clear Night Vision:

With clear night vision. The camera of this doorbell with infrared detection, which is sensitive to identify light sensing. When in the nighttime, it will automaticaly switch to night mode. Even in the night, you also can monitor the outdoor environment.

installation steps ：

Step 1: Select the screws with suitable length according to the thickness of the door, and twist the screw into the rod nut of the outdoor unit.

Step 2: Tear off the off -skid pads on the bottom of the outdoor unit, push the guide rod and the lines through the door holes and force

The outdoor machine is pasted on the door (pay attention to the direction of the outdoor unit: the detection sensor faces the front above, and the doorbell button is below below). The screw card is tightened on the gourd hole on the hanging plate until the screws and the outdoor machine are fixed firmly.

Step 4: Insert the TF card into the host.

Step 5: Connect the cable to the connector on the back of the indoor machine.

Step 6: Align the four hooks on the back of the indoor machine on the hooks on the hanging panel, hang in, and pull the indoor machine down to the lock state.

Product Size ：

Packaging size: 18.50*12.50*7.50

packing list

：

Indoor machine x1 outdoor unit X1 stand X1

screw x3 power cord X1 instruction manual X1
